1st M.2 highest PCIe generation: | 4.0 |
1st M.2 largest key size: | 2280 |
2nd M.2 highest PCIe generation: | 4.0 |
2nd M.2 largest key size: | 2280 |
ACPI version: | 5.0 |
ATX Power connector (24-pin): | Yes |
Audio output channels: | 7.1 channels |
Chipset (motherboard): | Intel |
Color: | Brown |
Compatible processor series: | Intel® Celeron® Intel® Core i3 12th Gen Intel® Core i3 13th Gen Intel® Core i3 14th Gen Intel® Core i5 12th Gen Intel® Core i5 13th Gen Intel® Core i5 14th Gen Intel® Core i7 12th Gen Intel® Core i7 13th Gen Intel® Core i7 14th Gen Intel® Core i9 12th Gen Intel® Core i9 13th Gen Intel® Core i9 14th Gen, Intel® Pentium ® Gold |
DVI-D port(s) quantity: | 0 |
DisplayPorts quantity: | 1 |
ECC сompatibility: | ECC & Non-ECC |
Ethernet LAN: | Yes |
Ethernet LAN RJ-45 port(s) quantity: | 1 |
Ethernet interface type: | 10/ 100/ 1000 Mbps |
Form factor (Motherboard): | Micro-ATX |
Front panel audio connector: | Yes |
Front panel connector: | Yes |
HDCP support: | Yes |
HDMI port(s) quantity: | 1 |
Maximum memory size: | 256 GB |
Maximum resolution: | 4096x2304 pixels |
Memory clock-frequency: | 4400 MHz 4800 MHz 5200 MHz 5600 MHz
|
Memory clock-frequency (max): | 5600 MHz |
Memory module type: | DIMM |
Memory number of slots: | 4 |
Memory type: | DDR5 |
Multi-GPU (SLI/CrossfireX) support: | Not supported |
Number of HDDs supported: | 4 |
Number of M.2 (M) slots: | 2 |
Number of SATA III connectors: | 4 |
PCIe x1 (Gen 3.x) slots: | 2 |
PCIe x16 (Gen 4.x) slots: | 1 |
PS/2 port(s) quantity: | 1 |
Processor manufacturer: | Intel |
Processor socket: | LGA1700 |
Processor socket(s) supported: | LGA1700 |
RAID support: | Yes |
S/PDIF-out port: | Yes |
Storage interfaces supported: | M.2, Serial-ATAIII |
