1st M.2 highest PCIe generation: | 4.0 |
1st M.2 largest key size: | 2280 |
ATX Power connector (24-pin): | Yes |
Audio output channels: | 7.1 channels |
Bluetooth port: | Yes |
Chipset (motherboard): | Intel |
Color: | Grey |
Compatible processor series: | Intel® Celeron® Intel® Core i3 12th Gen Intel® Core i3 13th Gen Intel® Core i3 14th Gen Intel® Core i5 12th Gen Intel® Core i5 13th Gen Intel® Core i5 14th Gen Intel® Core i7 12th Gen Intel® Core i7 13th Gen Intel® Core i7 14th Gen Intel® Core i9 12th Gen Intel® Core i9 13th Gen Intel® Core i9 14th Gen, Intel® Pentium ® |
DVI-D port(s) quantity: | 0 |
DisplayPorts quantity: | 1 |
ECC сompatibility: | ECC & Non-ECC |
Ethernet LAN: | Yes |
Ethernet LAN RJ-45 port(s) quantity: | 1 |
Ethernet interface type: | 10/ 100/ 1000 Mbps |
Form factor (Motherboard): | Micro-ATX |
Front panel audio connector: | Yes |
Front panel connector: | Yes |
HDCP support: | Yes |
HDMI port(s) quantity: | 1 |
Maximum memory size: | 128 GB |
Maximum resolution: | 4096x2304 pixels |
Memory clock-frequency: | 2133 MHz 2400 MHz 2666 MHz 2933 MHz 3000 MHz 3200 MHz 3300 MHz 3333 MHz 3400 MHz 3466 MHz 3600 MHz 3666 MHz 3733 MHz 3800 MHz 3866 MHz 4000 MHz 4133 MHz 4266 MHz 4300 MHz 4400 MHz 4500 MHz 4600 MHz 4700 MHz 4800 MHz 4933 MHz 5000 MHz 5133 MHz 5333 MHz
|
Memory clock-frequency (max): | 5333 MHz |
Memory module type: | DIMM |
Memory number of slots: | 4 |
Memory type: | DDR4 |
Multi-GPU (SLI/CrossfireX) support: | Not supported |
Number of HDDs supported: | 4 |
Number of M.2 (M) slots: | 2 |
Number of SATA III connectors: | 4 |
PCIe x1 (Gen 3.x) slots: | 2 |
PCIe x16 (Gen 4.x) slots: | 1 |
PS/2 port(s) quantity: | 1 |
Processor manufacturer: | Intel |
Processor socket: | LGA1700 |
Processor socket(s) supported: | LGA1700 |
RAID support: | Yes |
S/PDIF-out port: | Yes |
Storage interfaces supported: | M.2, Serial-ATAIII |
Trusted Platform Module (TPM) connector: | Yes |
USB2.0 port(s) quantity: | 2 |
