ATX Power connector (24-pin): | Yes |
Audio output channels: | 7.1 channels |
Chipset (motherboard): | Intel |
Color: | Brown |
Compatible processor series: | Intel® Celeron® Intel® Core i3 Intel® Core i5 Intel® Core i7 Intel® Core i9, Intel® Pentium ® Gold |
DVI-D port(s) quantity: | 0 |
DisplayPorts quantity: | 2 |
ECC сompatibility: | ECC & Non-ECC |
Ethernet LAN: | Yes |
Ethernet LAN RJ-45 port(s) quantity: | 1 |
Ethernet interface type: | 10/ 100/ 1000 Mbps |
Form factor (Motherboard): | Micro-ATX |
Front panel audio connector: | Yes |
Front panel connector: | Yes |
HDCP support: | Yes |
HDMI port(s) quantity: | 1 |
Maximum memory size: | 128 GB |
Maximum resolution: | 4096x2304 pixels |
Memory clock-frequency: | 2133 MHz 2400 MHz 2666 MHz 2933 MHz 3000 MHz 3200 MHz 3300 MHz 3333 MHz 3400 MHz 3466 MHz 3600 MHz 3666 MHz 3733 MHz 3800 MHz 3866 MHz 4000 MHz 4133 MHz 4266 MHz 4300 MHz 4400 MHz 4500 MHz 4600 MHz 4700 MHz 4800 MHz 4933 MHz 5000 MHz 5133 MHz 5333 MHz
|
Memory clock-frequency (max): | 5333 MHz |
Memory module capacities supported: | 1 GB 2 GB 4 GB 8 GB 12 GB 16 GB 32 GB |
Memory module type: | DIMM |
Memory number of slots: | 4 |
Memory type: | DDR4 |
Multi-GPU (SLI/CrossfireX) support: | Not supported |
Number of HDDs supported: | 4 |
Number of M.2 (M) slots: | 2 |
Number of SATA III connectors: | 4 |
PCIe x1 (Gen 3.x) slots: | 1 |
PCIe x1 slots: | 1 |
PCIe x16 (Gen 3.x) slots: | 1 |
PCIe x16 (Gen 4.x) slots: | 1 |
PCIe x16 slots: | 1 |
PCIe x4 slots: | 1 |
PS/2 port(s) quantity: | 1 |
Processor manufacturer: | Intel |
Processor socket: | LGA1700 |
Processor socket(s) supported: | LGA1700 |
RAID support: | Yes |
S/PDIF-out port: | Yes |
SATA connectors quantity: | 4 |
