1st M.2 highest PCIe generation: | 4.0 |
1st M.2 largest key size: | 2580 |
2nd M.2 highest PCIe generation: | 4.0 |
2nd M.2 largest key size: | 25110 |
ACPI version: | 5.0 |
ATX Power connector (24-pin): | Yes |
Audio output channels: | 7.1 channels |
Chipset (motherboard): | AMD |
Compatible processor series: | AMD Ryzen 7000 Series AMD Ryzen 8000 Series AMD Ryzen 9000 Series |
Cooling type: | Passive |
DVI-D port(s) quantity: | 0 |
DisplayPorts quantity: | 2 |
ECC сompatibility: | Non-ECC |
Ethernet LAN: | Yes |
Ethernet LAN RJ-45 port(s) quantity: | 1 |
Ethernet interface type: | 2.5 Gigabit Ethernet |
Form factor (Motherboard): | Micro-ATX |
Front panel audio connector: | Yes |
Front panel connector: | Yes |
HDCP support: | Yes |
HDMI port(s) quantity: | 1 |
Maximum memory size: | 256 GB |
Maximum resolution: | 4096x2160 pixels |
Memory clock-frequency: | 8200 MHz 8000 MHz 7950 MHz 7900 MHz 7800 MHz 7600 MHz 7400 MHz 7200 MHz 7000 MHz 6800 MHz 6666 MHz 6600 MHz 6400 MHz 6200 MHz 6000 MHz 5600 MHz 5200 MHz 4800 MHz 4400 MHz |
Memory clock-frequency (max): | 8200 MHz |
Memory module type: | DIMM |
Memory number of slots: | 4 |
Memory type: | DDR5 |
Multi-GPU (SLI/CrossfireX) support: | Not supported |
Number of HDDs supported: | 4 |
Number of M.2 (M) slots: | 2 |
Number of SATA III connectors: | 4 |
PCIe x16 (Gen 3.x) slots: | 1 |
PCIe x16 (Gen 4.x) slots: | 1 |
PS/2 port(s) quantity: | 1 |
Processor manufacturer: | AMD |
Processor socket: | Socket AM5 |
Processor socket(s) supported: | Socket AM5 |
RAID support: | Yes |
Storage interfaces supported: | M.2, PCIe 4.0, Serial-ATAIII |
Trusted Platform Module (TPM) connector: | Yes |
